RSE is a developer and manufacturer of industrial water-heating and steam boilers operating on biomass (sawdust, wood chips, bark, straw, chipboard and fiberboard waste, peat, pellets, woodworking waste, cones, sunflower husks) and natural gas.
It combines traditions and innovations, is inspired by the ideas of the most famous Czech inventor Erich Rouchka and the experience of modern designers.
RSE provides individual energy solutions for all industries and communities in Europe, develops boiler equipment of any complexity individually for each customer with the highest possible efficiency and compliance to the strictest environmental standards.
An oil-fired boiler is often used in place of traditional oil-fired steam and water boilers and is usually chosen for its ability to reach higher temperatures at lower operating pressures.
According to the steam table for conventional water and steam boilers, high steam temperatures require equally high pressures. Temperatures up to 300°C can be reached in a non-pressurized hot fuel oil boiler, and temperatures up to 400°C can be reached in a pressurized hot fuel oil boiler.
Acceptable fuel
Advantages of thermal oil plant:
Advantages of thermal oil plant:
- Corrosion has been eliminated
- High operating temperatures, usually up to 300 °C near atmospheric pressure
- No need for treated and preheated feed water
- Relatively silent operation – no phase change and steam shocks
The design of the boilers is three-pass with a flame tube, a rear rotating chamber cooled by water, a closed membrane wall, two-pass heat pipes, an uncooled second (front) rotating chamber and a smoke collector.
The boilers are supplied as a standard right-hand version (right-hand control). At the request, boilers can be supplied in the left version.
Above the flange for connecting the burner and in the rear rotating chamber there are inspection holes for optical control of the flame tube. For internal boiler inspection, hatches and holes are installed in the boiler body.
All heating surfaces are easily accessible for cleaning, which ensures constant high efficiency, even with long-term operation of the boiler on liquid fuel. The boiler materials and seamless pipes were used to comply with EN 10028 and EN 10216.
